EPS 708 – common-rail pump test bench
The EPS 708 test bench for common-rail diesel pumps and injectors enables diesel specialists to carry out highly accurate testing of diesel components.
Advanced electronics deliver precision at every level: Injection quantities are measured electronically for cost-effective testing, electronic regulation is at work throughout the various test stages and intelligent self-diagnosis prompts technicians on filter change. This test bench is designed for excellent performance – and designed to last.
More Information
Features and Benefits
- Specialist test bench: Designed for CP1, CP3, CP (Delphi, Denso, Siemens), Solenoid valve CRI (Bosch, Delphi, Denso), Solenoid valve CRIN (Bosch), CRI Piezo (Bosch, Siemens, Denso)
- Rail designed for pressures up to 2,500 bar: Be prepared and extend current testing pressure level (2,200 bar) with add-on kit as diesel technology develops in the future
- Engine shutdown feature: Safety first! Opening hood immediately cuts engine to protect users
- Electronic monitoring of service level intervals: Keep the test bench operating at its most efficient level
- Optional integrated cooling system: An effective way to use less water
- Built-in database: Integrate vehicle data and test values within efficient workflows
- Intuitive interface: Straightforward for technicians to learn and use with confidence
- 200 V and 400 V options available: Choice to suit your workshop set-up
Technical Data
Degree of protection | IP 43 |
Degree of protection
Input frequency
|
IP 43
50/60 Hz
|
Degree of protection
Output
|
IP 43
8 KW
|
Degree of protection
Number of phases
|
IP 43
3 P/PE
|
Degree of protection
Standstill torque (motor)
|
IP 43
23 Nm
|
Degree of protection
Maximum torque (motor)
|
IP 43
61 Nm
|
Degree of protection
Speed range
|
IP 43
0 – 4,000 rpm
|
Degree of protection
Customer-provided in-series fuse
|
IP 43
40 A
|
Degree of protection
Maximum permissible ambient temperature
|
IP 43
40°C
|
Degree of protection
Axis height (clamping bed height to injection pump axis center)
|
IP 43
110 mm
|
Zero-backlash multi-plate clutch according to | 2,600 ISO Nm/° |
Zero-backlash multi-plate clutch according to
Rail designed for pressures up to
|
2,600 ISO Nm/°
250 Mpa
|
Zero-backlash multi-plate clutch according to
Test pressure
|
2,600 ISO Nm/°
18 – 220 Mpa
|
Zero-backlash multi-plate clutch according to
Pre-supply-pump pressure
|
2,600 ISO Nm/°
10 – 500 kPa
|
Zero-backlash multi-plate clutch according to
Lubricating oil pressure (special accessories)
|
2,600 ISO Nm/°
100 – 600 kPa
|
Zero-backlash multi-plate clutch according to
Test oil
|
2,600 ISO Nm/°
approx. 55 l
|
Zero-backlash multi-plate clutch according to
Retaining capacity for contaminated oil
|
2,600 ISO Nm/°
approx. 10 l
|
Zero-backlash multi-plate clutch according to
Lubrication oil (special accessories)
|
2,600 ISO Nm/°
approx. 8 l
|
Zero-backlash multi-plate clutch according to
Dimensions (W x H x D)
|
2,600 ISO Nm/°
2,100 x 1,850 x 790 mm
|
Zero-backlash multi-plate clutch according to
Weight
|
2,600 ISO Nm/°
900 kg
|
Scope of Delivery
- Test bench
- CRS 845 H
- 19“ TFT monitor
- PC with CD/DVD drive
- Mouse
- Mains connection lead
- Hydraulic hoses
- Software package
- Protective cover
- UK keyboard
- EPS 708 without cooling (400 V):
Part number: 0 683 708 001 - EPS 708 with integrated cooling (400 V):
Part number: 0 683 708 020
